800-1000 nits Indoor P5 960*540mm 16:9 Cabinet Aluminum Fixed LED Display
Product Description:
FX-BLOCK series led panels are adopting aluminum profile frame is the highest cost performance LED display for indoor led projects. Due to fixed installation, we have developed a special pixel pitch P5 LED panel that is different from the market. With special modules and cabinet sizes, which can help your product and project stand out in the market.
Features:
- 16:9 Gold ratio:Module size:480*270mm;Cabinet size:960*540mm
- Thin and light:Single cabinet 11.5kg,thickness 58mm
- Module magnet design:Power box can be individually removed.
- Modular design:Front/Rear service
- Quick and easy installation
Technical Parameters:
| Technical Parameters | Iutdoor Fixed LED Display Screen |
| Product Model: | FX-BLOCK |
| Pixel Pitch: | 5 mm |
| LED Type: | SMD2121 |
| Cabinet Dimension: | 960x540 mm |
| Cabinet Resolution: | 192*108 pixels |
| Module Size: | 480x270 mm |
| Module Resolution: | 96*54 pixels |
| Module Qty/cabinet: | 2x2=4pcs |
| Pixel Density: | 40000 dots/sqm |
| Cabinet Weight: | 12 kg |
| Cabinet Material: | Aluminum profile |
| Driving Type: | 1/9 |
| Brightness: | 800-1000 nits |
| Max/Avg Power: | 540/190 W/m2 |
| Maintenance: | Front/Rear service |
| Environment: | Indoor Use |
| IP Rating: | IP20/IP43(Optional) |
| Refresh Rate: | >3840 Hz |
| Installation Type: | Mounting/Hanging/Stacking |
| Gray Scale: | 14 bits |
| Viewing Angle: | H:140°；V:140° |
| Operational Temp: | -20℃~+50℃ |
| Operational Humidity: | 10%~90% RH |
Applications:
Visual World's Indoor Fixed LED Display, with the model number P3.75, is the ultimate solution for all your indoor visual needs. Made with high-quality materials and advanced technology, this product is designed to provide a seamless and high-definition viewing experience.
Our Indoor Fixed LED Display is suitable for a wide range of indoor applications, including but not limited to:
- Indoor advertising
- Retail stores
- Shopping malls
- Concerts and events
- Transportation hubs
Packing and Shipping:
Your products will be well protected & packaged,then will be shipped to you as soon as possible by Ship,Air or Express according to you requirement.
FAQ:
Q1: Why choose Green Visual World?
A1: How to Select = High Quality + Strict Quality Control + Aging Time + Prompt Shipping Time + Professional & Quick Reply + Risk Free
Visual World = Assured Quality + 5 Steps Strict QC + 72 Hours Aging Time + Ship as fast as we can + Superior 99.8% Customer Satisfaction + 2 Years Warranty.
Q2: What kind of LED display do you offer?
A2: Our products cover LED full color display for indoor and outdoor, Rental LED Display, LED advertisement display, LED stage display, LED irregular-shape display, truck mobile led display, LED sports display, LED traffic information display etc.
Q3: Are there big differences in vision and price?
A3: Yes. The closer the pixel distance, the clearer the display screen can be seen, and the price is relatively high.
